Literature

  Brochure PDF File
A2A Heat Exchanger Full Line Brochure PDF
A2A Heat Exchanger Full Line Product Sheets PDF
Model Body Style Watts/°F Watts/°C Voltage / Hz Running Amps Max Ambient Temp °F HxWxD
A2AC040126 Compact 6 11 120 50/60 .37 160°F 16.5" x 11" x 3.5"
A2AC040236 Compact 6 11 230 50/60 .18 160°F 16.5" x 11" x 3.5"
A2AC040D24 Compact 6 11 24VDC .80 160°F 16.5" x 11" x 3.5"
A2AC040D48 Compact 6 11 48VDC .40 160°F 16.5" x 11" x 3.5"
A2AC080126 Compact 12 22 120 50/60 .37 160°F 16.5" x 11" x 3.5"
A2AC080236 Compact 12 22 230 50/60 .18 160°F 16.5" x 11" x 3.5"
A2AC080D24 Compact 12 22 24VDC .80 160°F 16.5" x 11" x 3.5"
A2AC080D48 Compact 12 22 48VDC .40 160°F 16.5" x 11" x 3.5"
A2AD120126 Deep 18 33 120 50/60 .37 160°F 16.5" x 11" x 5.5"
A2AD120236 Deep 18 33 230 50/60 .18 160°F 16.5" x 11" x 5.5"
A2AD120D24 Deep 18 33 24VDC .80 160°F 16.5" x 11" x 5.5"
A2AD120D48 Deep 18 33 48VDC .40 160°F 16.5" x 11" x 5.5"
A2AD160126 Deep 24 44 120 50/60 .37 160°F 16.5" x 11" x 5.5"
A2AD160236 Deep 24 44 230 50/60 .18 160°F 16.5" x 11" x 5.5"
A2AD160D24 Deep 24 44 24VDC .80 160°F 16.5" x 11" x 5.5"
A2AD160D48 Deep 24 44 48VDC .40 160°F 16.5" x 11" x 5.5"
A2AS040126 Slim 6 11 120 50/60 .37 160°F 21.00" X 5.6" X 11"
A2AS040236 Slim 6 11 230 50/60 .18 160°F 21.00" X 5.6" X 11"
A2AS040D24 Slim 6 11 24VDC .80 160°F 21.00" X 5.6" X 11"
A2AS040D48 Slim 6 11 48VDC .40 160°F 21.00" X 5.6" X 11"
A2AS080126 Slim 12 22 120 50/60 .37 160°F 21.00" X 5.6" X 11"
A2AS080236 Slim 12 22 230 50/60 .18 160°F 21.00" X 5.6" X 11"
A2AS080D24 Slim 12 22 24VDC .80 160°F 21.00" X 5.6" X 11"
A2AS080D48 Slim 12 22 48VDC .40 160°F 21.00" X 5.6" X 11"
A2AS120126 Slim 18 33 120 50/60 .37 160°F 21.00" X 5.6" X 11"
A2AS120236 Slim 18 33 230 50/60 .18 160°F 21.00" X 5.6" X 11"
A2AS120D24 Slim 18 33 24VDC .80 160°F 21.00" X 5.6" X 11"
A2AS120D48 Slim 18 33 48VDC .40 160°F 21.00" X 5.6" X 11"
A2AS160126 Slim 24 44 120 50/60 .37 160°F 21.00" X 5.6" X 11"
A2AS160236 Slim 24 44 230 50/60 .18 160°F 21.00" X 5.6" X 11"
A2AS160D24 Slim 24 44 24VDC .80 160°F 21.00" X 5.6" X 11"
A2AS160D48 Slim 24 44 48VDC .40 160°F 21.00" X 5.6" X 11"
A2AT260126 Tall 40 71.6 120 50/60 .47 160°F 29" x 13.88 x 5.5"
A2AT260236 Tall 40 71.6 230 50/60 .243 160°F 29" x 13.88 x 5.5"
A2AT260D24 Tall 40 71.6 24VDC 1.94 160°F 29" x 13.88 x 5.5"
A2AT260D48 Tall 40 71.6 48VDC .928 160°F 29" x 13.88 x 5.5"
A2AT200126 Tall 31 55 120 50/60 .47 160°F 29" x 13.88 x 5.5"
A2AT200236 Tall 31 55 230 50/60 .243 160°F 29" x 13.88 x 5.5"
A2AT200D24 Tall 31 55 24VDC 1.94 160°F 29" x 13.88 x 5.5"
A2AT200D48 Tall 31 55 48VDC .928 160°F 29" x 13.88 x 5.5"

  Machine Drawings Cutout Templates
Model PDF File DWG File PDF File DWG File
Product Compact Drawings PDF DWG PDF DWG
Product Deep Drawings PDF DWG PDF DWG
Product Slim Drawings PDF DWG PDF DWG
Product Tall Drawings PDF DWG PDF DWG
